SpiroCross -Brass -Magnet

10 Bar
Max 110°C

A brass low loss header with (microbubble) deaerator and dirt separator with a 1" - 1½" connection and magnet

The benefits of the SpiroCross AX-J hydraulic balancer with deaerator & dirt separator with magnet

  • Three functions in one single component.
  • Hydraulic balancing and air & (magnetic) dirt separation.
  • Hydraulic separation of the primary and secondary sides of the heating/cooling system so they do not interfere with each other.
  • Maximising system performance: better and more precise regulation of the heating system.
  • Insulation set available (TAX150).
  • Optimal hydraulic balance between primary and secondary pumps.
  • Powerful neodymium magnet guarantees an unrivalled fast and optimum dirt separation. Even the smallest magnetite particles are removed.
  • Collected dirt can be quickly and easily removed while the system remains fully operational.
  • Large collection chamber ensures that frequent flushing is not necessary. Factory-installed integral air vent continuously removes circulating air and micro-bubbles.
  • Provides optimum heat transfer with constant low pressure drops.
  • No bypass, isolating valves and replacement filters that can clog and cause reduced flow.
  • Maintenance only takes a few seconds and is not a dirty job compared to a filter solution.
  • Robust compact brass housing (no corrosion) with a limited built-in height.
  • Quick and easy installation.
  • Spirotech quality & technology with 20 years warranty.

Variation specifications


ETIM Specifications
