A steel (air) deaerator and dirt separator for high flow rate (3 m/s) with a DN50 - DN150 weld connection
Diameter: | DN 50 |
DN/d | DN 50 |
OD | 60.3 |
D | 159 |
L/LF | 260 |
y | >50 |
e | Rp1 |
e1 | G3/4 |
e2 | R1/2 |
h | 405 |
h1 | 505 |
x | >200 |
Diameter: | DN 65 |
DN/d | DN 65 |
OD | 76.1 |
D | 159 |
L/LF | 260 |
y | >50 |
e | Rp1 |
e1 | G3/4 |
e2 | R1/2 |
h | 405 |
h1 | 505 |
x | >200 |
Diameter: | DN 80 |
DN/d | DN 80 |
OD | 88.9 |
D | 219 |
L/LF | 370 |
y | >50 |
e | Rp1 |
e1 | G3/4 |
e2 | R1/2 |
h | 525 |
h1 | 620 |
x | >200 |
Diameter: | DN 100 |
DN/d | DN 100 |
OD | 114.3 |
D | 219 |
L/LF | 370 |
y | >50 |
e | Rp1 |
e1 | G3/4 |
e2 | R1/2 |
h | 525 |
h1 | 620 |
x | >200 |
Diameter: | DN 125 |
DN/d | DN 125 |
OD | 139.7 |
D | 324 |
L/LF | 525 |
y | >50 |
e | Rp1 |
e1 | G3/4 |
e2 | R1/2 |
h | 745 |
h1 | 825 |
x | >200 |
Diameter: | DN 150 |
DN/d | DN 150 |
OD | 168.3 |
D | 324 |
L/LF | 525 |
y | >50 |
e | Rp1 |
e1 | G3/4 |
e2 | R1/2 |
h | 745 |
h1 | 825 |
x | >200 |
The SpiroCombi should preferably be installed at the hottest point in the system. For a heating system, this is the point where the system water leaves the heater. In a cooling system, it should be installed in the return line, just before it enters the cooler.
