SpiroVent -Steel -Weld

A steel (microbubble) deaerator for standard flow rate (1.5 m/s) with a DN50 - DN150 weld connection

The benefits of the BA-L SpiroVent Deaerators

  • Removes all circulating air and microbubbles effectively
  • Removes trapped air when installed at the correct location
  • Greatly reduces the need for manual venting
  • Applicable with 50/50 Glycol / Water (Volume)
  • Constant low-pressure drop
  • No unnecessary shutdown
  • Weld connections
  • Connection diameters from DN50 to DN150, larger diameters available on request
  • Exceptional guarantee

Product variants

Select the desired connection below and get all (technical) productdata!

Article number BA050L
Product type SpiroVent -DN50 -Weld

The positioning of a SpiroVent air deaerator in the system

SpiroVent Air deaerators are preferably positioned at the hottest point of the installation, the point where the water leaves the heater or where the water enters the cooler.
